High Quality Digital Photo Colorimeter
Brand Name: Skytech
Model: S-404
Origin : India
Technical Data :
- Accuracy : +0.020.D
- Reproducibility : +0.010.D
- Stability : +0.01 0.D per hour
- Light source : 6.8 V, 0.3 Amps. Tungsten lamp
- Amplifie : I.C. based
- Detector : Celenium Photocell
- Warm Up time : 5 minutes
- Display : 2 and Half Digit LED Display to read visible range
- Sample System : 12 mm dia matched
- Sample Size : 1.0 ml
- Power Supply : 230V+ 10% 50 Hz. A.C(And or 6 X1.5V dry cell for Better Operated Mode Optional)
- Weight : 4 Kg. (APPROX)
- Dimensions : L 245xB 185xH 90mm
STANDARD ACCESSORIES
- Test Tubes (Mate hed) : 5 Nos.
- Dust Cover : 1 No.
- Instruction Manual : 1 No.
FILTERS
| COLOUR | PEAK | RANGE |
| VOILET | 400 nm | 380 TO 430 nm |
| VOILET BLUE | 420 nm | 400 TO 460 nm |
| GREENISH BLUE | 480 nm | 470 TO 510 nm |
| BLUE GREEN | 500 nm | 480 TO 530 nm |
| BLUSH GREEN | 520 nm | 490 TO 550 nm |
| GREEN | 540 nm | 500 TO 580 nm |
| ORANGE | 620nm | 580 TO 640 nm |
| RED | 680 nm | 630 TO 700 nm |
On the filter disc only two most significant digit of wave
lenght are used 520 nm is indicated by 52.
